A D-STAR Hotspot is a transceiver that is usually connected to a D-STAR repeater or reflector, using the internet connection at the host's site, and allows persons with a D-STAR transceiver to join in on the D-STAR network. Since it is a simplex frequency two stations do not talk to each other through the hotspot. Its main purpose is to allow individials to talk on the repeater or reflector where the hotspot is connected. The W4LKS hotspot responds to standard DPLUS commands for linking, echo, inquiry, etc. Feel free to disconnect and connect to other repeaters and reflectors (including X reflectors).
The hotspot also supports Yaesu System Fusion digital voice communications. It is connected to the YSF network and allows rooms on that network. By default, It is connected to the Parrot room. If you key up using a fusion digital radio, you will hear your own transmissions played back to you. If you know how to switch to other rooms, you are welcome to do so.
Since the W4LKS hotspot is usually connected to REF035C, when you talk on it, you will be heard on the WA7DRE repeater and other D-STAR repeaters connected to REF035C as well.
Operating Frequency: 441.500 mhz simplex D-STAR DV mode
Required D-STAR field settings: URCALL: CQCQCQ RPT1: W4LKS B RPT2: W4LKS G
Antenna: Diamond X300A mounted 10' above the roof
Radio: Yaesu FTM-310 on High power (50 watts)
GMSK (RF) to Digital Interface: Repeater-Builder STM32-DVM v4
Internet Connection: Raspberry Pi 4 using wired ethernet
D-STAR connectivity software: WPSD version of Pi-Star
Connected to: D-STAR Reflector REF035C (usually) and Fusion digital Parrot
Other Features: ircddb remote (ask for permission), X Reflectors, APRS forwarding, D-RATS forwarding
Dashboard Page: http://cheneyhs.shacknet.us
Green = Handheld coverage, Yellow = Base or Mobile coverage
